WCF Payment

This documentation provides details on how to interact with the WCF Payment API. Ensure you have the necessary API keys and tenant information before proceeding.

Getting Started

License

In order to run WCF Payment API the Totalview license Salary and Project API is required.

Build your API call

Your API call must include the following components:

  1. Host: The host for Payment API Requests is https://TENANTNAME.totalview.cloud/PAYWCFAPI.

  2. Authorization header: Include the API Key in the header as x-api-key.

  3. Request type: Use POST method to submit JSON payload data.

Locate your API key

The API key is registered in the TimeServer.exe.config file in the installation directory of the TimeServer.

<?xml version="1.0" encoding="utf-8"?>
<configuration>
    ...
    <appSettings>
        ...
        <add key="WCFPaymentApiKey" value="YOUR_API_KEY"/>
        ...
    </appSettings>
    ...
</configuration>

Note

The API key can be changed without needing to restart the TimeServer.

Test if connection can be established

Run this url in the browser (or with any GET request) and verify you get the response Hello World.

https://TENANTNAME.totalview.cloud/PAYWCFAPI/hello?msg=World

Get basic data

Note

Replace TENANTNAME and YOUR_API_KEY with your actual tenant name and API key.

Get a list of Users

To get a list of users from the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/GetUsers' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '
'

Request

Empty

Response

Will return a list of TRSPaymentUsers.

TRSPaymentUser

  • RecID int - the Id of the user

  • ShortName string - The short name of the user

  • Name string - The name of the user

  • CustomFields TRSCustomField[] - A list of customfields the user has

TRSCustomField

  • Caption string - The custom filed caption (e.g. Capability)

  • Values string - The value of the custom field (e.g. Developer)

Get a list of approved users

To get a list of approved users from the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/GetApprovedUsers' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '{
    "FromDate": "\/Date(1262304000000)\/",
    "ToDate": "\/Date(1577836800000)\/"
}
'

Request

  • FromDate DateTime - note: this field must be set to unix time in milliseconds

  • ToDate DateTime - note: this field must be set to unix time in milliseconds

Response

Will return a list of TRSPaymentUsers.

TRSPaymentUser

  • RecID int - the Id of the user

  • ShortName string - The short name of the user

  • Name string - The name of the user

  • CustomFields TRSCustomField[] - A list of customfields the user has

TRSCustomField

  • Caption string - The custom filed caption (e.g. Capability)

  • Values string - The value of the custom field (e.g. Developer)

Get a list of balances

To get a list of balances from the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/GetBalances' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '
'

Request

Empty

Response

Will return a list of TRSPaymentBalance.

TRSPaymentBalance

  • RecID int - the Id of the balance

  • Name string - The name of the balance

Get a list of all attachments fields

To get a flat list of all active attachment fields from the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/GetAttachments' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '
'

Request

Empty

Response

Will return a list of TRSPaymentAttachments.

TRSPaymentAttachment

  • ID string - The Field ID

  • Name string - The Field Caption

Insert balance regulations

To insert balance regulations to the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/InsertBalanceRegulations' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '{
    "regulations" : {
        "RegulationHeader": {
            "Comment": "",
            "ExternalId": ""
        },
        "BalanceRegulationEntries": [
            {
                "ResourceRecId": 1,
                "Duration": 1,
                "BalanceId": 1,
                "CountDate": "\/Date(1262304000000)\/",
                "Description": "Test"
            }
        ]
    }
}
'

Request

  • regulations BalanceRegulations

BalanceRegulations

  • RegulationHeader AccountRegulationHeader

  • BalanceRegulationEntries BalanceRegulationEntry[]

AccountRegulationHeader

  • Comment string - The comment for the inserted balance regulation

  • ExternalId string - The external id of the inserted balance regulation

BalanceRegulationEntry

  • ResourceRecId int - The Id of the User for the balance regulation

  • Duration int - The total duration in seconds

  • BalanceId int - The balance Id. Must be a valid id from GetBalances

  • CountDate DateTime - The date to insert the balance regulation. note: this field must be set to unix time in milliseconds

  • Description string - The description of the balance regulation

Response

Will return a InsertAccountRegulationsResult.

InsertAccountRegulationsResult

  • Successfull bool - True if inserted successfully else false.

  • ErrorSQL string - If success is false then the sql error is given.

  • ErrorMessage string - if success is false the error message is given.

  • MasterRecId int - The master id of the inserted balance regulation.


Export of Records

These are methods for exporting records to payment systems. These are the states payment records can be before calling methods

../../../_images/wcf-payment-states.png

Note

Replace TENANTNAME and YOUR_API_KEY with your actual tenant name and API key.

Get a list of payment records

To get a list of payment records for a given list of user ids from the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/GetPaymentRecords' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '{
    "FromDate": "\/Date(1262304000000)\/",
    "ToDate": "\/Date(1577836800000)\/",
    "UserRecIDs": [
        {
            "RecID": 115
        },
        {
            "RecID": 124
        }
    ]
}
'

Request

  • FromDate DateTime - note: this field must be set to unix time in milliseconds

  • ToDate DateTime - note: this field must be set to unix time in milliseconds

  • UserRecIDs - A list of TRSPaymentRecID. If empty all users are taken.

TRSPaymentRecID

  • RecID int - The Id of a user

Response

Will return a list of TRSPaymentRecords.

TRSPaymentRecords

  • TransactionKey int - The Transaction Key that will be used for handling the transaction.

  • UserRecords TRSPaymentUserRecord[] - List of payment records

TRSPaymentUserRecord

  • UserRecID int - The Id of the user.

  • RecID int - The Id of the payment record.

  • CountDate DateTime - The date the payment record is for.

  • TimeStart DateTime - The datetime the record started.

  • TimeEnd DateTime - The datetime the record ended.

  • Duration int - The total duration in seconds.

  • BalanceRecID int - The Id of the balance.

  • Attachment string - The attachment in XML.

  • Description string - The decription of the registration that resulted in this payment record.

Export records for a transaction

To export records for a transaction in the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/ExportRecords' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '{
    "TransactionKey" : "197"
}
'

Request

  • TransactionKey int - The transaction key given by GetPaymentRecords

Response

Will return a boolean true or false based on if the export was successful.

Post records for a transaction

To post records for a transaction in the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/PostRecords' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '{
    "TransactionKey" : "197"
}
'

Request

  • TransactionKey int - The transaction key given by GetPaymentRecords

Response

Will return a boolean true or false based on if the post was successful.

Rollback records for a transaction

To rollback records for a transaction in the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/RollbackRecords' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '{
    "TransactionKey" : "197"
}
'

Request

  • TransactionKey int - The transaction key given by GetPaymentRecords

Response

Will return a boolean true or false based on if the rollback was successful.

Delete records for a transaction

To delete records for a transaction in the API:

curl --location 'https://TENANTNAME.totalview.cloud/PAYWCFAPI/DeleteRecord' \
--header 'x-api-key: YOUR_API_KEY' \
--header 'Content-Type: application/json' \
--data '{
    "PaymentRecordID" : "197"
}
'

Request

  • PaymentRecordID int - The payment record id to delete

Response

Will return a boolean true or false based on if the delete was successful.
